1.5kw 2hp Solar Water Pump VFD Motor Controller 3 Phase 380V Frequency Inverter

Contact Now* Send an Inquiry to this supplier.
or
Start Order * Name your price

Browse by Category

Contact us

Shenzhen M-Driver Technology Co., Ltd
[China]

Address
Building D1, Hengli Industrial Shenzhen Guangdong
Phone
86-0755-89369291
Contact name
Andy Gao

Quick Information

  • Brand Name: Mdriver
  • Place of Origin: China
  • Model Number : S0015G1
  • Input Voltage : 220V
  • Output Current : 7A
  • Output Frequency : between0Hzand500Hz
  • Output Power : 1.5kw
  • Output Type : Triple
  • Output Voltage : 220V
  • Size : 142mmx85.5mmx113mm
  • Type : DC/AC Inverters
  • Weight : 0.8kg
  • :

Description

1.5kw 2hp Solar Water Pump VFD Motor Controller 3 phase 380V Frequency Inverter

frequency converter freqency inverter ac driver

Product Description

Application 01



Features

____________________________________________________________________________________________________________________



1. MPPT control

With high accuracy MPPT algorithms, tracking the PV array output by the maximum power point, driving the pump motor to meet various pump applications in agriculture, irrigation etc.



 2. Supports AC&DC input

 The system is powered by the solar panels regularly. When the sunlight is not good, the system can also be powered by AC grid.



3.Dry protection

 If there's no water in the ground, the water pump will stop working automatically and when the water comes, the system starts to work automatically.



 4. Auto sleep&Wake:

 The pump will slow down automatically when the sunlight is weak , and it will sleep and wake automatically as the sulight .



5. Smart water level control

The water level in the tank can also be controlled . The inverter will sleep when the water level is above maxium water level and it will wake up automatically when it's under the minimum water level. The maximum and minimum water level can be set by the user.









Specifics

________________________________________________________________________________________________________





220V Solar Pumping Inverter
Input Specification
PV input
Maxiumum input DC voltage 400V DC
Recommended MPPT voltage range 250~350V DC
Recommended input Operation Voltage 310V DC
Grid or backup generator input
Input voltage Single phase 220V(-15%~30%)
Output Specification
Rated output voltage 3PH 220V
Output frequency 0~500.00Hz (default: 0~50.00Hz)
380V Solar Pumping Inverter
Input Specification
PV input
Maxiumum input DC voltage 800V DC
Recommended MPPT voltage range 450~600V DC
Recommended input Operation voltage 540V DC
Grid or backup generator input
Input voltage Three phase 380V(-15%~30%)
Output specification
Rated ouput voltage 3PH 380V
Output frequency 0~500.00Hz (default: 0~50.00Hz)
Protection
Built-in Protection Lighting Protection ,over-current, overvoltage, ouput phase lose, under-load, under-voltage, short circuit , overheating, water pump run dry etc.
General Parameters
Application site No direct sunshine, no dust,corrosive gas,combustible gas, oil mist, steam,dripping or salinity etc.
Altitude 0~2000m
Derated use above 1000m, per 100m, the rated output current decrease 1%
Environment Temperature -10°C~40°C (Environment Temperature be 40°C~50°C, please keep derated use)
 Humidity  5~95%, non-condensation
 Vibration  less than 5.9 m/s²(0.6G)
 Storage Temperature  -20°C~+70°C
 Efficiency  Rated Power Run≥93%
 Installation  Wall or rail mounting
 Protectiion Grade  IP20
 Cooling  Forced Air Cooling



Type Drive motor Power capacity Input current Output current Shape case
KW KVA A A
Single phase power supply: 220V, 50/60A
PV500-0004M1 0.4 0.5 5.4 2.5 000
PV500-0007M1 0.75 1 8.2 4 000
PV500-0015M1 1.5 2 14 7 000
PV500-0007G1 0.75 1 4.2 4 001
PV500-0015G1 1.5 2 14 7 001
PV500-0022G1 2.2 3 23 10 001
Three phase power supply; 220V ,50/60hz
PV500-0040G2 4 5 18.1 16 002
PV500-0055G2 5.5 7.5 28 25 003
PV500-0075G2 7.5 10 37.1 32 003
PV500-0110G2 11 15 49.8 45 004
PV500-0150G2 15 20 65.4 60 004
PV500-0185G2 18.5 25 81.6 75 004
PV500-0220G2 22 30 97.7 90 005
PV500-0300G2 30 40 122.1 110 005
PV500-0370G2 37 50 157 150 006
PV500-0450G2 45 60 185 170 006
PV500-0550G2 55 70 215 210 007
PV500-0750G2 75 100 320 300 007
Three phase power supply: 380V ,50/60hz
PV500-0007G3 0.75 1 3.4 2.1 001
PV500-0015G3 1.5 2 5 3.8 001
PV500-0022G3 2.2 3 5.8 5 001
PV500-0040G3 4 5 10.5 9 002
PV500-0055G3 5.5 7.5 14.6 13 002
PV500-0075G3 7.5 10 20.5 17 002
PV500-0110G3 11 15 26 25 003
PV500-0150G3 15 20 35 32 003
PV500-0185G3 18.5 25 38.5 38 003
PV500-0220G3 22 30 46.5 45 004
PV500-0300G3 30 40 62 60 004
PV500-0370G3 37 50 76 75 004
PV500-0450G3 45 60 92 90 005
PV500-0550G3 55 70 113 110 005
PV500-0750G3 75 100 157 150 006
PV500-0930G3 93 125 180 170 006
PV500-1100G3 110 150 214 210 007
PV500-1320G3 132 175 256 250 007
PV500-1600G3 160 210 307 300 007
PV500-1850G3 185 250 385 340 008
PV500-2000G3 200 260 385 380 008
PV500-2200G3 220 300 430 415 008
PV500-2500G3 250 350 468 470 008
PV500-2800G3 280 370 525 520 008
PV500-3150G3 315 400 590 585 009





Product details

_______________________________________

frequency inverter detail0.75-2.2kw0.75kw VFD drive.jpg0.75kw VFD.jpg0.4kw solar pump inverter



Connection diagram

_______________________________________





Cell power lower 15kwGrid power higher 18kw

Application

Application VFD.jpg





Packaging & Shipping

packing for VFD.jpg9.webp

Company Information

inverters factory.jpgAdvantages.jpg





 Frequency Inverters FAQ.jpg

FAQ



Q 1: Are you trading company or manufacturer ?

We are factory.


Q 2: How long is your lead time?

Generally 3-7 days if the goods are in stock, or 10-20 days if the stocks are not enough, it is according to quantity.


Q 3: Do you provide samples ? is it free or extra ?
Yes, we provide samples and charge for the samples with freight cost. The sample fees will be returned if the order quantity over 500pcs.


Q 4: What is your terms of payment ?
We accept T/T(30% deposit, 70% balance), L/C and CASH.


Q 5: What is the standard of package?

Single small carton or plywood crate.


Q 6. Is there any discount ?

The discount will depend on the quanlity you purchase.


Q 7. What is your supply capacity?

The daily production is 500pcs.


Q 8. Do you provide warranty for the goods?

Yes, we provide 18 months warranty for all the goods.


Q 9. Could M-driver provide technical support?

Yes, we worked 19 years in this field and have a lot of experienced engineers, they will provide solutions if get a problem.




Certificates

  • CE : ATSL170304911

Price

  • Delivery Port : Shenzhen

Packaging & Delivery

  • Packing :The product will be packed in a single small carton or a plywood crate.
  • Packaging Size : 15.3 x 10.2 x 11.8  Centimeters
  • Package Weight : 0.8  Kilograms
  • Delivery Lead Time : 7 days
  • Supply Ability : 3000 pcs per day

Product Image

  • 1.5kw 2hp Solar Water Pump VFD Motor Controller 3 Phase 380V Frequency Inverter image
